Plateau coulissant PRR
PRR
Zoom
Zoom
Zoom

Sliding flat top

The PRR “green spaces” sliding flat top is particularly possible because of its low loading angle, ideal for every type of equipment, even with a small ground clearance. This sliding flat top is based on a double axle and we propose sizes and payloads adapted to every type of use.

As a standard fixture, this sliding bed ensures the hydraulic sliding of the bed and comes with a rear ramp and extra low wheels. This “sliding flat top” range comes with many different options (fold-down and removable sides, cage sides, adjustable parallelogram hitching…).

The possible alternatives for this sliding top trailer, depending on your use, can include: large tipper trailer or very large tipper trailer or large tipper bed or also the very large tipper bed.

Designed and made in France

  • Caracteristiques

    • Welded metal chassis, hot-dip galvanized
    • Flat bed without sides.
    • Hydraulic flat top sliding
    • Spare wheel bracket
    • Rear ramp, height 0.60 m
    • Large section jockey wheel
    • Non-skid wooden floor.
    • Inertia brake with auto-reverse.
    • Type-approved recessed lighting.

    Options

    • Spare wheel.
    • Side and front rack, height 0.15 m.
    • Removable and folding sides, 0.40 m high
    • Cage sides, height 0.80 m.
    • Winch bracket.
    • Manual winch.
    • Winch cable guide (mandatory if sides).
    • Adjustable wheel chocks every 15 cm over 1 m.
    • Tie down rings (per pair).
    • Antitheft device.
    • OPTIMA extra-low adjustable parallelogram hitch.
      GVW 2000/2500 kg / MIN 300 mm / MAX 830 mm
      GVW 3200 kg / MIN 300 mm / MAX 820 mm
    Tableau de prix

    * Informal indications liable to change.
    With a constant concern to improve the quality of its equipment, the manufacturer reserves the right to change the characteristics given in this document, without prior notice.
